Description
The SmartSolar MPPT 75/15 Retail converts solar-panel output into controlled battery charging for 12V / 24V systems. Bluetooth enables local setup and monitoring through VictronConnect. Adaptive charging settings allow the installation to be matched to the battery manufacturer’s requirements.
Key specifications
- Battery voltage: 12V / 24V
- Rated charge current: 15 A
- Maximum PV open-circuit voltage: 75 V
- Nominal PV power at 12 V: 220 W
- Nominal PV power at 24 V: 440 W
- Data communication: Bluetooth,VE.Direct
- Weight: 0.5 kg
- Dimensions (H × W × D): 100 mm × 113 mm × 40 mm
- Protection rating: IP43 (electronic components)
Included
- SmartSolar MPPT 75/15 Retail charge controller
Installation notes
Size the array by its cold-weather open-circuit voltage and current, not wattage alone. Install with suitable cable protection and ventilation. Solar panels, batteries, external monitoring equipment and installation materials are not included.
Warranty
Victron Energy provides a standard 5-year limited warranty on power products, subject to its warranty policy and exclusions. Contact the original supplier for claims.
Condition: Brand new.
