Description
The Apollo AP-DA214 is designed to power an additional listening area without using a full-size amplifier. Its supplied bracket supports a tidy installation, and the status LED helps identify operating conditions.
Use only with compatible Fusion DSP-enabled marine audio equipment and Fusion speakers. Configure the appropriate DSP profile through the compatible app after installation. RCA interconnects, suitable power cabling and the required inline fuse or circuit breaker are not included.
Key specifications
- Channels: 2
- Amplifier class: Class D
- RMS output at 4 ohms: 2 x 20 W at 14.4 V, less than 1% THD+N
- RMS output at 2 ohms: 2 x 30 W at 14.4 V, less than 1% THD+N
- Peak output: 140 W
- Operating voltage: 10.8–32 V DC
- Dimensions without bracket: 100 x 100 x 40 mm
- Dimensions with bracket: 100 x 115 x 48 mm
- Weight: 460 g
- Water rating: IPX7
- Frequency response: 20 Hz–20 kHz
In the box
- Apollo AP-DA214 zone amplifier
- Mounting bracket
- Three 6-gauge self-tapping screws
- Wiring loom
- Installation instructions
- Important safety and product information
Warranty
3-year manufacturer limited warranty, subject to Garmin/Fusion terms and proof of purchase. Standard owner-installation cover does not include onboard labour or travel.
Condition: Brand new.
Manufacturer product information | Manufacturer warranty details
